Nomad X0 AXS RSV 2024
Build Kit & Specs
*Please note: we make every effort to ensure accuracy of spec information, but they are subject to change.
| Frame | |
|---|---|
| Material | |
| Features | |
| Frame | |
| Travel | |
| Weight | |
| Wheel Size | |
| Suspension | |
| Fork | |
| Shock | |
| Remote | |
| Drivetrain | |
| Bottom Bracket | |
| Cassette | |
| Chain | |
| Chainguide | |
| Crank Length | |
| Crankset | |
| Front Derailleur | |
| Left Shifter | |
| Rear Derailleur | |
| Right Shifter | |
| Shifters | |
| Brakes | |
| Brakes | |
| Front Brakes | |
| Front Rotor | |
| Rear Brakes | |
| Rear Rotor | |
| Rotors | |
| Cockpit | |
| Bar Width | |
| Dropper Length | |
| Grips / Bar Tape | |
| Handlebars | |
| Headset | |
| Saddle | |
| Seatpost | |
| Stem | |
| Stem Length | |
| Wheels | |
| Front Rim | |
| Front Hub | |
| Front Tire | |
| Rear Rim | |
| Rear Hub | |
| Rear Tire | |
| Valves | |
| Rims | |
| Ebike | |
| Battery | |
| Drive Unit | |
| Battery Charger | |
| Specs | |
| Bottom Bracket Shell | |
| Rear Brake Mount | |
| Chainguide_standard | |
| Chainline | |
| Derailleur Hanger | |
| Shock Length | |
| Fork Axle to Crown | |
| Fork Compatibility | |
| Fork Offset | |
| Front Derailleur Mount | |
| Headset | |
| Max Chainring Size | |
| Max Rotor Size | |
| Max Tire Clearance | |
| Rear Spacing | |
| Rear Travel | |
| Recommended Sag | |
| Sealant | |
| Seat Clamp Diameter | |
| Seat Post Diameter | |
| Shock Bushing Size Front | |
| Shock Bushing Size Rear | |
| Shock Mounting Hardware Lower | |
| Shock Mounting Hardware Upper | |
| Shock Stroke | |
| Suspension System | |
| UDH Compatible | |
| Water Bottle Mounts |
Nomad X0 AXS RSV 2024
Sizing & Geometry
If you're on the cusp between the recommended height range of two sizes, the absolute best thing is to try to ride them both. At a minimum, check the stack/reach measurements on your current bike and compare it to the new model you are looking at to get an idea of a fit you are already comfortable with. If riding the bike is not an option, consider the following.
| s | m | l | xl | xxl | |
|---|---|---|---|---|---|
| Reach (Hi/Lo) | 430/427 | 455/452 | 475/472 | 495/492 | 520/517 |
| Stack (Hi/Lo) | 616/618 | 625/627 | 638/640 | 656/658 | 670/672 |
| Head Tube Angle (Hi/Lo) | 63.8/63.5 | 63.8/63.5 | 63.8/63.5 | 63.8/63.5 | 63.8/63.5 |
| Seat Tube Angle (Hi/Lo) | 77.2/77 | 77.4/77.2 | 77.9/77.6 | 77.8/77.5 | 77.7/77.5 |
| Wheelbase (Hi/Lo) | 1209/1209 | 1239/1240 | 1269/1270 | 1301/1302 | 1336/1337 |
| Front Center (Hi/Lo) | 770/770 | 799/799 | 826/826 | 855/855 | 886/886 |
| Rear Center (Hi/Lo) | 439/440 | 440/441 | 443/444 | 446/447 | 450/451 |
| BB Height (Hi/Lo) | 346/343 | 346/343 | 346/343 | 346/343 | 346/343 |
| BB Drop Front (Hi/Lo) | 27/30 | 27/30 | 27/30 | 27/30 | 27/30 |
| BB Drop Rear (Hi/Lo) | 8/11 | 8/11 | 8/11 | 8/11 | 8/11 |
| Standover Height (Hi/Lo) | 709/705 | 716/713 | 723/719 | 722/717 | 725/720 |
| Head Tube Length | 90/90 | 100/100 | 115/115 | 135/135 | 150/150 |
| Seat Tube Length | 380/380 | 405/405 | 430/430 | 460/460 | 500/500 |
| Top Tube Length (Hi/Lo) | 570/571 | 594/594 | 612/613 | 637/638 | 666/667 |
Nomad X0 AXS RSV 2024
Setup & Support
Whether you’re the proud owner of a Nomad or are just digging deep into the details you’ll find it all here.
| Rider Weight (lbs) | Rider Weight (kgs) | Pressure (psi) | Rebound (from closed) | Compression (L/H from middle) |
|---|---|---|---|---|
| 100 | 45 | 29 | 15 | -2,middle |
| 120 | 54 | 37 | 13 | -2,middle |
| 140 | 64 | 45 | 12 | -2,middle |
| 160 | 73 | 54 | 11 | -2,middle |
| 180 | 82 | 62 | 10 | -2,middle |
| 200 | 91 | 70 | 9 | -2,middle |
| 220 | 100 | 78 | 8 | -2,middle |
| 240 | 109 | 86 | 6 | -2,middle |
| Rider Weight (lbs) | Rider Weight (kgs) | Spring Rate | Sag | Preload | Rebound (from closed) | Compression (L/H from middle) |
|---|---|---|---|---|---|---|
| 100 | 45 | 250 | 26-28%, 17-19mm | 1-2 turns | 9 | -2,middle |
| 120 | 54 | 300 | 26-28%, 17-19mm | 1-2 turns | 8 | -2,middle |
| 140 | 64 | 350 | 26-28%, 17-19mm | 1-2 turns | 7 | -2,middle |
| 160 | 73 | 400 | 26-28%, 17-19mm | 1-2 turns | 6 | -2,middle |
| 180 | 82 | 450 | 26-28%, 17-19mm | 1-2 turns | 5 | -2,middle |
| 200 | 91 | 500 | 26-28%, 17-19mm | 1-2 turns | 5 | -2,middle |
| 220 | 100 | 550 | 26-28%, 17-19mm | 1-2 turns | 4 | -2,middle |
| 240 | 109 | 600 | 26-28%, 17-19mm | 1-2 turns | 4 | -2,middle |
| label | part_number | quantity | name | blurb |
|---|---|---|---|---|
| A | 29-23753 | 1 | Upper Link | |
| B | 11-12681 | 2 | 6900-2RS Bearing | |
| C | 26-15533 | 2 | M10x3 Washer | Apply grease to inner surface |
| D | 26-11612 | 2 | Bearing Dust Shield | Apply grease to inner surface |
| E | 11-12218 | 2 | 6902-2RS Max Bearing | |
| F | 26-17013 | 1 | 15x40.25 Bearing Spacer |
| label | part_number | quantity | name | blurb | torque |
|---|---|---|---|---|---|
| A | 29-23751 | 1 | Lower Link | ||
| B | 11-17708 | 4 | 6902-1ZR Bearing | ||
| C | 26-11612 | 4 | Bearing Dust Shield | Apply grease to inner surface | |
| D | 26-19126 | 1 | 15x28 Bearing spacer | ||
| E | 26-17013 | 1 | 15x40.25 Bearing Spacer | ||
| F | 26-12678 | 1 | M6 Grease Fitting | 9 Nm | |
| G | 26-15532 | 1 | M5x5 Set Screw | Apply Loctite 242 to threads, titghten until flush |
| label | part_number | quantity | name | torque | blurb |
|---|---|---|---|---|---|
| A | 26-22843 | 1 | Glovebox lid | ||
| B | 26-25333 | 1 | Glovebox bezel | ||
| C | 26-23284 | 4 | M3x8 BHCS | 0.5 Nm | Apply Loctite 242 to threads |
| D | 30-23225 | 2 | Glovebox nut | ||
| E | 26-22358 | 1 | M3x6 | 0.6 Nm | Apply Loctite 242 to threads |
| F | 30-22620 | 1 | Storage Bulkhead | Install inside Downtube |
| label | part_number | quantity | name | blurb | torque |
|---|---|---|---|---|---|
| A | 08-22208 | 1 | Rear axle 12x168.5 | Apply grease to shaft and threads | |
| B | 23-23491 | 1 | SCB UDH | Interchangeable with Sram UDH | |
| C | 26-23492 | 1 | SCB UDH screw | Reverse thread | 20 Nm |
| D | 30-20361 | 1 | Chainstay Protector | ||
| E | 26-15939 | 1 | M3x12 BHCS | Apply grease to treads | 0.5 Nm |
| F | 30-21453 | 1 | Seatstay Protector | ||
| G | 49-21567 | 1 | Lower Link Fender | ||
| H | 26-18382 | 2 | M4x12 BHC | Apply grease to treads | 0.65 Nm |
| label | part_number | quantity | torque | name | blurb |
|---|---|---|---|---|---|
| A | 26-20122 | 2 | 16 Nm | M10x23 Screw | Apply Loctite 242 to threads only, apply grease to shaft only |
| B | 26-22461 | 2 | 20 Nm | M8x45 Shock Bolt | Apply Loctite 242 to threads |
| C | 26-21452 | 1 | M8x2 Flip Chip NDS | Apply grease to surface | |
| D | 26-21451 | 1 | M8x2 Flip Chip DS | Apply grease to surface | |
| E | 26-15947 | 2 | 9 Nm | M6x20 SHCS | Apply Loctite 242 to threads |
| F | 26-11817 | 2 | M6 Washer | ||
| G | 26-15633 | 2 | M6 Tapered Washer | Apply grease to surface | |
| H | 08-22343 | 1 | 20 Nm | Pivot Axle M15x91 | Apply Loctite 242 to threads only, apply grease to shaft only |
| I | 08-16292 | 1 | 20 Nm | Pivot axle M15x80.5 | Apply Loctite 242 to threads only, apply grease to shaft only |
| J | 08-16291 | 1 | 20 Nm | Pivot axle M15x68.5 | Apply Loctite 242 to threads only, apply grease to shaft only |
| label | part_number | quantity | name | blurb | torque |
|---|---|---|---|---|---|
| A | 67-19217 | 1 | Head Tube Badge | Clean frame surface, center on headtube | |
| B | 30-23750 | 1 | Shuttle Guard Mount | ||
| C | 30-22560 | 1 | Shuttle Guard | ||
| D | 26-21249 | 2 | M4x8 BHCS | Apply grease to threads | 0.65 Nm |
| E | 30-23718 | 1 | Downtube Protector | ||
| F | 26-18382 | 2 | M4x12 BHC | Apply grease to treads | 0.65 Nm |
| G | 34-20201 | 1 | 36.4 Seat Collar |
