Bronson Frame 2024
Build Kit & Specs
*Please note: we make every effort to ensure accuracy of spec information, but they are subject to change.
| Frame | |
|---|---|
| Material | |
| Features | |
| Frame | |
| Travel | |
| Weight | |
| Wheel Size | |
| Suspension | |
| Fork | |
| Shock | |
| Remote | |
| Drivetrain | |
| Bottom Bracket | |
| Cassette | |
| Chain | |
| Chainguide | |
| Crank Length | |
| Crankset | |
| Front Derailleur | |
| Left Shifter | |
| Rear Derailleur | |
| Right Shifter | |
| Shifters | |
| Brakes | |
| Brakes | |
| Front Brakes | |
| Front Rotor | |
| Rear Brakes | |
| Rear Rotor | |
| Rotors | |
| Cockpit | |
| Bar Width | |
| Dropper Length | |
| Grips / Bar Tape | |
| Handlebars | |
| Headset | |
| Saddle | |
| Seatpost | |
| Stem | |
| Stem Length | |
| Wheels | |
| Front Rim | |
| Front Hub | |
| Front Tire | |
| Rear Rim | |
| Rear Hub | |
| Rear Tire | |
| Valves | |
| Rims | |
| Ebike | |
| Battery | |
| Drive Unit | |
| Battery Charger | |
| Specs | |
| Bottom Bracket Shell | |
| Rear Brake Mount | |
| Chainguide_standard | |
| Chainline | |
| Derailleur Hanger | |
| Shock Length | |
| Fork Axle to Crown | |
| Fork Compatibility | |
| Fork Offset | |
| Front Derailleur Mount | |
| Headset | |
| Max Chainring Size | |
| Max Rotor Size | |
| Max Tire Clearance | |
| Rear Spacing | |
| Rear Travel | |
| Recommended Sag | |
| Sealant | |
| Seat Clamp Diameter | |
| Seat Post Diameter | |
| Shock Bushing Size Front | |
| Shock Bushing Size Rear | |
| Shock Mounting Hardware Lower | |
| Shock Mounting Hardware Upper | |
| Shock Stroke | |
| Suspension System | |
| UDH Compatible | |
| Water Bottle Mounts |
Bronson Frame 2024
Sizing & Geometry
If you're on the cusp between the recommended height range of two sizes, the absolute best thing is to try to ride them both. At a minimum, check the stack/reach measurements on your current bike and compare it to the new model you are looking at to get an idea of a fit you are already comfortable with. If riding the bike is not an option, consider the following.
| xs | s | m | l | xl | |
|---|---|---|---|---|---|
| Reach (Hi/Lo) | 405/402 | 430/427 | 455/452 | 475/472 | 500/497 |
| Stack (Hi/Lo) | 594/595 | 617/619 | 626/628 | 635/637 | 649/651 |
| Head Tube Angle (Hi/Lo) | 64.7°/64.5° | 64.7°/64.5° | 64.7°/64.5° | 64.7°/64.5° | 64.7°/64.5° |
| Seat Tube Length (Hi/Lo) | 370/370 | 380/380 | 405/405 | 430/430 | 460/460 |
| Front Center (Hi/Lo) | 722/722 | 757/757 | 786/786 | 811/810 | 842/842 |
| BB Height (Hi/Lo) | 344/341 | 344/341 | 344/341 | 344/341 | 344/341 |
| BB Drop Front (Hi/Lo) | 10/13 | 29/32 | 29/32 | 29/32 | 29/32 |
| BB Drop Rear (Hi/Lo) | 10/13 | 29/32 | 29/32 | 29/32 | 29/32 |
| Wheelbase (Hi/Lo) | 1149/1154 | 1188/1189 | 1221/1222 | 1249/1249 | 1284/1285 |
| Rear Center (Hi/Lo) | 427/432 | 431/432 | 435/436 | 438/439 | 442/443 |
| Head Tube Length (Hi/Lo) | 110/110 | 100/100 | 110/110 | 120/120 | 135/135 |
| Top Tube Length (Hi/Lo) | 536/542 | 570/575 | 599/604 | 623/627 | 653/657 |
| Seat Tube Angle (Hi/Lo) | 77.6°/76.9° | 77.2°/76.7° | 77.1°/76.6° | 76.9°/76.5° | 76.7°/76.4° |
| Standover Height (Hi/Lo) | 701/698 | 709/706 | 731/727 | 729/726 | 728/725 |
Bronson Frame 2024
Setup & Support
Whether you’re the proud owner of a Bronson or are just digging deep into the details you’ll find it all here.
| label | part_number | quantity | name | blurb | torque |
|---|---|---|---|---|---|
| A | 67-19217 | 1 | Head Tube Badge | Clean frame surface, center on headtube | |
| B | 30-22560 | 1 | Shuttle Guard | ||
| C | 30-23750 | 1 | Shuttle Guard Mount | ||
| D | 26-21249 | 2 | M4x8 BHCS | Apply grease to threads | 0.65 Nm |
| E | 30-23718 | 1 | Downtube Protector | For Bronson without Glovebox, use 30-21457 | |
| F | 26-18382 | 2 | M4x12 BHC | Apply grease to treads | 0.65 Nm |
| G | 30-23225 | 2 | Glovebox nut | ||
| H | 26-25333 | 1 | Glovebox bezel | ||
| I | 26-23284 | 4 | M3x8 BHCS | Apply Loctite 242 to threads | 0.5 Nm |
| J | 26-22843 | 1 | Glovebox lid | ||
| K | 26-22358 | 1 | M3x6 | Apply Loctite 242 to threads | 0.6 Nm |
| L | 30-22620 | 1 | Storage Bulkhead | Install inside Downtube | |
| M | 34-20201 | 1 | 36.4 Seat Collar |
| label | part_number | quantity | torque | name | blurb |
|---|---|---|---|---|---|
| A | 26-20122 | 2 | 16 Nm | M10x23 Screw | Apply Loctite 242 to threads only, apply grease to shaft only |
| B | 26-22461 | 2 | 20 Nm | M8x45 Shock Bolt | Apply Loctite 242 to threads |
| C | 08-22343 | 1 | 20 Nm | Pivot Axle M15x91 | Apply Loctite 242 to threads only, apply grease to shaft only |
| D | 08-16291 | 1 | 20 Nm | Pivot axle M15x68.5 | Apply Loctite 242 to threads only, apply grease to shaft only |
| E | 08-16292 | 1 | 20 Nm | Pivot axle M15x80.5 | Apply Loctite 242 to threads only, apply grease to shaft only |
| F | 26-15633 | 3 | M6 Tapered Washer | Apply grease to surface | |
| G | 26-11817 | 3 | M6 Washer | ||
| H | 26-15947 | 3 | 9 Nm | M6x20 SHCS | Apply Loctite 242 to threads |
| I | 26-21452 | 1 | M8x2 Flip Chip NDS | Apply grease to surface | |
| J | 26-15532 | 1 | M5x5 Set Screw | Apply Loctite 242 to threads, titghten until flush | |
| K | 26-19207 | 2 | Hose Grommet |
| label | part_number | quantity | name | blurb | torque |
|---|---|---|---|---|---|
| A | 08-22209 | 1 | Rear axle 12x173.7 | Apply grease to shaft and threads | |
| B | 23-23491 | 1 | SCB UDH | Interchangeable with Sram UDH | |
| C | 26-23492 | 1 | SCB UDH screw | Reverse thread | 20 Nm |
| D | 30-20361 | 1 | Chainstay Protector | ||
| E | 26-15939 | 1 | M3x12 BHCS | Apply grease to treads | 0.5 Nm |
| F | 26-18382 | 2 | M4x12 BHC | Apply grease to treads | 0.65 Nm |
| G | 49-21567 | 1 | Lower Link Fender | ||
| H | 30-21453 | 1 | Seatstay Protector |
| label | part_number | quantity | name | blurb |
|---|---|---|---|---|
| A | 29-22534 | 1 | Upper Link | |
| B | 11-12681 | 2 | 6900-2RS Bearing | |
| C | 26-15533 | 2 | M10x3 Washer | Apply grease to inner surface |
| D | 11-12218 | 2 | 6902-2RS Max Bearing | |
| E | 26-11612 | 2 | Bearing Dust Shield | Apply grease to inner surface |
| F | 26-17012 | 1 | 15x34.25 Bearing Spacer |
| label | part_number | quantity | name | blurb | torque |
|---|---|---|---|---|---|
| A | 29-22533 | 1 | Lower Link | ||
| B | 11-17708 | 4 | 6902-1ZR Bearing | ||
| C | 26-11612 | 4 | Bearing Dust Shield | Apply grease to inner surface | |
| D | 26-19126 | 1 | 15x28 Bearing spacer | ||
| E | 26-17013 | 1 | 15x40.25 Bearing Spacer | ||
| F | 26-15532 | 1 | M5x5 Set Screw | Apply Loctite 242 to threads, titghten until flush | |
| G | 26-12678 | 1 | M6 Grease Fitting | 9 Nm |
| Frame Size | Flip Chip | Setup Key | Setup Cog | 30T | 32T | 34T | 36T |
|---|---|---|---|---|---|---|---|
| XSmall | High | B | 7 | 114 | 114 | 116 | 116 |
| Small | High | B | 7 | 114 | 116 | 116 | 118 |
| Medium | High | B | 7 | 116 | 116 | 118 | 118 |
| Large | High | B | 7 | 116 | 116 | 118 | 118 |
| XLarge | High | B | 7 | 116 | 118 | 118 | 120 |
| XSmall | Low | B | 7 | 114 | 116 | 116 | 118 |
| Small | Low | B | 7 | 114 | 116 | 116 | 118 |
| Medium | Low | B | 7 | 116 | 116 | 118 | 118 |
| Large | Low | B | 7 | 116 | 116 | 118 | 118 |
| XLarge | Low | B | 7 | 116 | 118 | 118 | 120 |
Bronson Frame 2024
Get access to the exclusive SCB Owners Club which gives you access to added levels of rider support, treats, opportunities and benefits. Join the club today for free! It takes just five minutes to receive a lifetime of membership perks.
Learn MoreWe build Santa Cruz bicycles to be durable and long lasting, and then back them up with legendary support and a warranty of the highest standard.
Santa Cruz Bicycles offers free replacement pivot bearings to the original owner for as long as they own their bike.
The 150mm-travel bike can go deep on any landing and the VPP™ suspension design makes sure that there’s no wasted energy when heading back up for another go. If you value style at speed or want to have fun feeling fast, then mixed wheels (29” up front, 27.5” out back) are the right choice. The larger front wheel provides more traction and stability that’ll make you feel more confident squaring off the turns and diving for the inside lines. But a 27.5-inch tire in the rear means this bike still loves getting up on the back wheel and into the air.
