Skitch 1 MY24

2023 - 2024

Land speed records every day

The Skitch is the ultimate city-slicking, traffic-flicking, alleycat-slipping, rat race-escaping teleportation device. The powerful and light motor gives you a nudge to spend less time behind a glass windscreen and more time with your knees in the breeze. You’ll look for even more excuses to get on your bike because even a city commute can be as much fun as bike park laps.

Carbon CC
Avant (MM) 0
Arrière (MM) 0
Taille de roues 700c
Puissance (W) 430
Batterie (Wh) 430
Unité motrice Fazua

Spécificités du modèle

Dégagement maximum des pneus 50mm
Mesure axe / té de fourche 430mm
Déport de la fourche (Offset) 45mm
Espacement arrière 148mm
Compatible UDH Yes
Jeu de direction IS 41 /IS52
Taille de plateau maximum 46t
Montage du frein arrière Flatmount 160mm Direct
Taille maximale des disques 180mm

Montages

Choisir un montage

Poids 30.14 lbs / 13.67 kg
Matériau Carbon CC
Taille de roues 700C
Fourche Carbon
Dérailleur arrière SRAM Apex Eagle, 12spd
Manette droite SRAM Apex
Cassette SRAM XG1275 Eagle, 12spd, 10-50t
Chaîne SRAM SX Eagle, 12spd
Jeu de direction Cane Creek 40 IS Integrated Headset
Pneu arrière Schwalbe G-One Overland Evo, 700x45c, ADDIX SpeedGrip
Pneu avant Schwalbe G-One Overland Evo, 700x45c, ADDIX SpeedGrip
Moyeu avant DT Swiss 370, 12x100, Centerlock, 28h
Jante avant WTB EZR i23p 700c
Moyeu arrière DT Swiss 370, 12x148, XD, Centerlock, 28h
Jante arrière WTB EZR i23p 700c
Disque avant Avid Centerline, Centerlock, 160mm
Disque arrière Avid Centerline, Centerlock, 160mm
Freins SRAM Apex
Pédalier Praxis eTor AL
Guidon Zipp Service Course 70 XPLR AL Bar
Potence Zipp Service Course Stem, 70mm
Selle WTB Silverado Medium, CroMo
Tige de selle Zipp Service Course, 27.2
Poignées Velo Bar Tape
Batterie Fazua 430 Wh Integrated Battery
Unité motrice Fazua Ride60
Chargeur Fazua Charger
Poids 29.83 lbs / 13.53 kg
Matériau Carbon CC
Taille de roues 700C
Fourche Carbon
Dérailleur arrière SRAM Apex Eagle, 12spd
Manette droite SRAM NX Eagle, 12spd
Cassette SRAM XG1275 Eagle, 12spd, 10-50t
Chaîne SRAM SX Eagle, 12spd
Jeu de direction Cane Creek 40 IS Integrated Headset
Pneu arrière Schwalbe G-One Overland Evo, 700x45c, ADDIX SpeedGrip
Pneu avant Schwalbe G-One Overland Evo, 700x45c, ADDIX SpeedGrip
Moyeu avant DT Swiss 370, 12x100, Centerlock, 28h
Jante avant WTB EZR i23p 700c
Moyeu arrière DT Swiss 370, 12x148, XD, Centerlock, 28h
Jante arrière WTB EZR i23p 700c
Disque avant Avid Centerline, Centerlock, 160mm
Disque arrière Avid Centerline, Centerlock, 160mm
Freins SRAM S-300
Pédalier Praxis eTor AL
Guidon RaceFace Ride
Potence RaceFace Ride, 80mm
Selle WTB Silverado Medium, CroMo
Tige de selle RaceFace Ride, 27.2
Poignées ESI Chunky Grips
Batterie Fazua 430 Wh Integrated Battery
Unité motrice Fazua Ride60
Chargeur Fazua Charger
Poids 30.03 lbs / 13.62 kg
Matériau Carbon CC
Taille de roues 700C
Fourche Carbon
Dérailleur arrière SRAM GX Eagle AXS T-Type, 12spd
Manette droite SRAM Rival AXS
Cassette SRAM GX Eagle T-Type, 10-52t
Chaîne SRAM GX Eagle T-Type, 12spd
Jeu de direction Cane Creek 40 IS Integrated Headset
Pneu arrière Schwalbe G-One Overland Evo, 700x45c, ADDIX SpeedGrip
Pneu avant Schwalbe G-One Overland Evo, 700x45c, ADDIX SpeedGrip
Moyeu avant DT Swiss 370, 12x100, Centerlock, 28h
Jante avant Easton ARC Offset 25 700c
Moyeu arrière DT Swiss 370, 12x148, XD, Centerlock, 28h
Jante arrière Easton ARC Offset 25 700c
Disque avant SRAM Paceline 160mm, Centerlock
Disque arrière SRAM Paceline 160mm, Centerlock
Freins SRAM Rival AXS
Pédalier Praxis eTor AL
Guidon Zipp Service Course 70 XPLR AL Bar
Potence Zipp Service Course Stem, 70mm
Selle WTB Silverado Medium, CroMo
Tige de selle Easton EC70, 27.2, Zero Offset, 350mm
Poignées Velo Bar Tape
Batterie Fazua 430 Wh Integrated Battery
Unité motrice Fazua Ride60
Chargeur Fazua Charger
Poids 30.13 lbs / 13.67 kg
Matériau Carbon CC
Taille de roues 700C
Fourche Carbon
Dérailleur arrière SRAM GX Eagle AXS T-Type, 12spd
Manette droite SRAM AXS Pod Bridge
Cassette SRAM GX Eagle T-Type, 10-52t
Chaîne SRAM GX Eagle T-Type, 12spd
Jeu de direction Cane Creek 40 IS Integrated Headset
Pneu arrière Schwalbe G-One Overland Evo, 700x45c, ADDIX SpeedGrip
Pneu avant Schwalbe G-One Overland Evo, 700x45c, ADDIX SpeedGrip
Moyeu avant DT Swiss 370, 12x100, Centerlock, 28h
Jante avant Easton ARC Offset 25 700c
Moyeu arrière DT Swiss 370, 12x148, XD, Centerlock, 28h
Jante arrière Easton ARC Offset 25 700c
Disque avant SRAM Paceline 160mm, Centerlock
Disque arrière SRAM Paceline 160mm, Centerlock
Freins SRAM Level Silver Stealth 2-Piston
Pédalier Praxis eTor AL
Guidon SRAM Atmos Flat Bar, 31.8x760
Potence SRAM Atmos Stem, 80mm
Selle WTB Silverado Medium, CroMo
Tige de selle OneUp V2 Dropper Post, 27.2
Poignées ESI Chunky Grips
Batterie Fazua 430 Wh Integrated Battery
Unité motrice Fazua Ride60
Chargeur Fazua Charger

Géométries

Toutes les mesures sont en millimètres ou en degrés.
s m l xl xxl
Reach 390 405 420 435 450
Stack 563 579 596 610 630
Head tube angle 69° 69° 69° 69° 69°
K. Longueur du tube de direction 105 125 145 160 180
G. Longueur des bases 430 430 430 430 430
Front Center 624 646 668 689 711
H. Hauteur du boitier 279 281 281 283 283
BB Drop 78 76 76 74 74
E. Empattement 1047 1070 1092 1112 1135
M. Longueur de tube supérieur 551 571 591 610 630
L. Longueur du tube de selle 455 485 515 545 575
Standover Height 728 753 778 804 830
D. Angle du tube de selle 74° 74° 74° 74° 74°

Guide des tailles

Small
154cm 5'1" - 167cm 5'6" Reach: 390mm
Medium
162cm 5'4" - 177cm 5'10" Reach: 405mm
Large
170cm 5'7" - 182cm 6'0" Reach: 420mm
X-Large
177cm 5'10" - 190cm 6'3" Reach: 435mm
XX-Large
185cm 6'1" - 198cm 6'6" Reach: 450mm

Réglage des suspensions

RS Rudy Base XPLR 40mm 700c
Poids du pilote (lbs) Poids du pilote (kg) Pression (psi) Rebond (unique)
100 45 81 12
120 54 100 10
140 63 119 8
160 72 138 6
180 81 157 4
200 90 177 3
220 99 196 1
240 108 215 0

Configuration de la transmission

Frame size Setup key Setup cog 34t 36t 38t 40t 42t 44t
Small A 7 116 118 118 120 120 122
Medium A 7 116 118 118 120 120 122
Large A 7 116 118 118 120 120 122
XLarge A 7 116 118 118 120 120 122

Vues éclatées

Motor Wiring Harness
label part_number quantity name blurb
A 72-24792 1 Fazua Ride 60 DU Wide
B 26-27248 4 Adhesive foam strip Apply to connector
Exploded Diagram of Skitch
Battery Mounting Hardware
label part_number quantity torque name blurb
A 26-25295 4 1.2 Nm M4x12 SHCS Apply Loctite 242 to threads
B 26-25136 1 Fix 430 mount
C 26-25283 2 9 Nm M6x10 BHCS Apply Loctite 242 to threads
D 78-24791 1 Fazua Energy 430 Fix
E 26-25137 1 Fix 430 mount
Exploded Diagram of Skitch
Seat Collar, Fender Mounts, and Bottle Cage Hardware
label part_number quantity name
A 34-20202 1 31.8 Seat Collar
B 26-20195 2 Fender Mount
C 26-21360 4 Water Bottle Screw
D 26-25139 1 DT Plug
Rear Axle, Derailleur Hanger, and Chainstay Protector
label part_number quantity name blurb torque
A 08-22209 1 Rear axle 173.7 Apply grease to shaft and threads
B 23-23491 1 SCB UDH Interchangeable with Sram UDH
C 26-23492 1 SCB UDH screw Reverse thread 20 Nm
D 26-15532 2 M5x5 Set Screw Apply Loctite 242 to threads, titghten until flush
E 30-20192 1 CS Protector
F 26-20124 1 M5x16 Water Bottle screw Apply grease to threads
G 26-20864 1 Di2 Plug
H 26-20865 1 Wireless Plug
I 26-15939 1 M3x12 BHCS Apply grease to treads 0.5 Nm
J 26-25140 1 Speed Sensor Cover
K 72-24782 1 Fazua speed sensor, medium wire
Exploded Diagram of Skitch
Frame Mounting Hardware
label part_number quantity name torque blurb
A 26-25196 1 Fazua charge port mount
B 72-24768 1 Fazua charge port cap
C 72-24771 1 Fazua Charge port, short wire
D 26-15938 1 M3x10 FHCS 0.65 Nm Apply Loctite 242 to threads
E 26-27112 1 Fazua charge port cover Used with range extender only
Exploded Diagram of Skitch
Motor, Motor Mounts, and Downtube Protector
label part_number quantity torque name blurb
A 26-23102 3 0.65 Nm M4x16 BHCS Apply grease to threads
B 26-25285 5 14 Nm M6x25 BHCS Apply Loctite 242 to threads
C 26-25284 1 14 Nm M6x35 BHCS Apply Loctite 242 to threads
D 30-25193 1 Downtube protector
E 26-25141 1 DU spacer
F 30-25194 1 DU protector
Exploded Diagram of Skitch
Head Badge and Control Unit
label part_number quantity name blurb
A 67-19217 1 Head Tube Badge Clean frame surface, center on headtube
B 26-25195 1 Head Tube Grommet
C 72-24784 1 Fazua LED Hub, long wire Insert foam tube 26-17568 onto long wire
Exploded Diagram of Skitch

Documents

Si vous cherchez davantage d'informations sur votre vélo, consultez le manuel d'utilisation.

FAQs

Yes. The Fazua battery passes UL-2271, and the electrical system passes UL-2849.

168mm

The Skitch is suspension-corrected for a 40mm gravel fork like the Rockshox Rudy or Fox Tapercast.

Learn all about the FAZUA RIDE 60 Drive System here: https://fazua.com/en/support/help-center/fazua-ride-60/ride-60-faqs/

Yes you can

Yes you can, you will need lights with the Fazua style power cord and a dealer can help get them installed.

The Fazua Ride 60 battery on the Skitch is desgined to be charged while inside the frame, and only removed for service.

Fazua firmware updates can be installed either via the Fazua phone app, through consumer Fazua Toolbox desktop software, or at your local Santa Cruz Bicycles dealer.

Absolutely. Learn more at Fazua's Garmin support page linked below, which includes the latest list of Garmin compatible devices, what data will display on your head unit, and how to connect each.
https://fazua.com/en/support/help-center/bluetooth-connections/fazua-dashboard-garmin-devices/

No, your bike is pre-programmed and ready to ride straight from the factory.

The FAZUA App connects to your bike via Bluetooth, and allows you to view live riding data (I.E. power output, & battery percentate of charge). You're also able to select different assist modes, download new riding profiles, and update your Fazua system's firmware.

Yes, you can download and learn more about it here: https://fazua.com/en/support/help-center/bluetooth-connections/fazua-app/

Fazua Ride 60 uses cranks with the ETOR spindle interface.

In the US, the Skitch is considered a Class 3 ebike with a 28mph max speed.
In Canada, the Skitch max speed is 32kph.

There is no throttle. The Skitch is pedal assist only.

The Skitch will hold two bottle cages without the range extender battery installed.

Yes. We designed it to work with up to 700x50mm while using fenders. Tires and fenders vary greatly, so treat these numbers as guidelines, not gospel.

Yes! We've included options for routing internally-routed dropper posts on the Skitch. Just make sure you order a 27.2mm post.

The frame will clear a 700x50mm size tire.
